| Brand Name : | Cheng Wen |
| Model Number : | CW--J3 |
| Certification : | CE |
| Payment Terms : | Western Union, MoneyGram, T/T |
| Supply Ability : | 1000 pieces per month |
| Delivery Time : | 3-5 work days |
3W RGB Disco DJ Laser Stage Light ,Full Color Animation Party
Lighting For Laser Show
Technical Datas
1. Voltage:AC90~240V 50~60HZ±10%
2. Power consumption:180W
3. Laser source:all diodes.
4. Laser power /wavelength:
1x500mW Red(638nm)
1x800mW Green (520nm )
1 x 1800mW Blue (445nm-455nm )
5. Beam size: 3*5mm at aperture
6. Divergence: <1.5mrad-full angle
6. Colors:RGB full color
7. External Modulation:TTL/Analog Optional
8. Laser Patterns:256 pieces built-in laser patterns
9. DMX Channel:12CH
10. Scanner system: 30kpps/ 20kpps optional.
11. Control signal:DMX-512 international standard signal
12. Control mode:Music,auto,master-slave and DMX-512l,ILDA Control.
13. Cooling system:fan
14. Operation environment :Indoor
15. Operation temperature: 10°C~40°C
16. Net Weight :6.5kg
17. Dimension Size : 27(L)x 15(w) x 13(H) cm
Laser descriptions
| Product Function: | *Animation RGB laser with high-speed optical scanner to create animated graphics, beam show and graphics show patterns, and with the function of unique blanking, frequently flashing, rotating, movement, billowing, zoom (+/-), drawing and speed, ect Laser Diode type: TE-cooled laser diodes |
Scan System | High speed XY Scanner Module(scan speed>30/40kpps;scan angle±35/45°;input signal ±5v;linearity distortion<2%) |
| Laser Color | Full Color |
| Laser Power | 638nm 500mW + 520nm 800mW + 445nm 1500mW, 3W,30kpps scanner |
System Port | DMX512 input and output port, ILDA DB standard port |
| Control Mode | Sound Active, Automatic, DMX512(24 channels), Master/Slave, Ilda Control |
| Demo Effect | Blanking, rotating, zooming, retroflexion, moving, strobe, used for words,Cartoons, and beam shows and laser advertisements |
| Power Supply | AC 85/220v 50-60HZ |
| Rating Power | 900W |
| Cooling System | Air cooling |
| Aplication | Discos, KTV, Bars, Clubs, Family parties, Opera House Advertisements etc |
Laser Show
After-sales Services
1.We are professional led stage lighting factory for three years,
technology in the industry is come out in front.
2.Our products can be OEM, to meet your special requirements.
3.We have rich experience R&D engineer and we have strong
ability for OEM projects.
4.We have wee-trained and professional sales&after- sale
services
5.For all your inquires about us or our products, we will reply you
in detail within 24 hours.
6.Our are quick delivery, competitive price, high quality and long
term service to our customer.
7.There is as long-term cooperation with the shipping company,can
make the goods more quickly and efficiently so that can delivered
safely to the designated place.
|
|
