| Ask Lasest Price | |
| Brand Name : | Cheng Wen |
| Model Number : | CW-P5/10 |
| Certification : | CE |
| Price : | $3418-708/sqm |
| Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 3000 pcs/month |
| Delivery Time : | 3-10/days |
Specification
| Item | Parameter |
| Model Number | P5 -8S |
| Module size | 320mm*160mm |
| Pixel pitch | 5mm |
| Pixels Density | 40000 dots/m2 |
| Pixel configuration | 1R1G1B |
| Package mode | SMD2727 |
| Pixel resolution | 64dots(W)*32 dots(H) |
| Drive type | Constant drive |
| Scan mode | 1/8scan |
| Port type | HUB75 |
| Brightness of white balance | 6500-7500cd/m2 |
| Dimension | 960mm*960mm |
| Quantity of Module | 18 |
| Power supply | 5V/40A |
| Pixel per cabinet | 192*192 |
| Weight | 28kg |
| Best viewing distance | >10m |
| Best viewing distance | 160°(W) 120°(H) |
| Temperature | storage:-35℃～+85℃ working:-20℃～+50℃ |
| Operation humidity | 10%-95% |
| Thickness | 15mm |
| Protection classification | IP65 |
| Working voltage | AC220V±10% |
| Max Power consumption | 800W/S |
| Average Power consumption | 450W/S |
| Product name | P10-4S |
| Pixel Pitch(mm)W*H | 10MM |
| Driving Mode | constant current |
| Pixel Density(dot/m²) | 10000 |
| LED type | SMD3528 |
| Cabinet Size(mm)W*H | 960*960MM |
| Cabinet Resolution | 32DOTS(W)*16DOTS(W) |
| Viewing Distance(m) | above 10m |
| Brightness(full white)(cd/m²) | 6500-6800cd/m² |
| Refresh Rate | 1920HZ |
| Transparency Rate | >80% |
| Weight(kg/pc) | 27.6 kg/pc |
| Viewing Angle | H:160°V:160° |
| Max. Power Consumption (W/m²) | 800 |
| Avg. Power Consumption (W/m²) | 240 |
| Signal Input | HDMI,DVI,VGA,RF,S-Video,RGB,RGBH,YUV,YC&Conposition,etc |
| Working Voltage | 380V±10% AC50HZ |
| Working Environment | -10℃～+45℃ 10%～80%RH |
| Life Span Time | ≥100000hours |
| Package | Flight Case/Wooden Case |
| Application | shopping mall ,supermarket,car shop |
Trade Terms:
| Price term | EXW , FOB (EXW Price in Guang zhou) |
| Payment | T/T, Western ,paypal |
| Shipping method | By express(DHL ,UPS,TNT,FedEx ), ship by sea or air |
| Sample Order/Time | Accept / 2 days |
| Production time | 3-7 days after receiving payment ,depend on the quantity |
| Packing | 1.Carton Packing(PE bag and EPE for safeguard that can protect from damage) 2. Flight case |
| Warranty | 2 years |
| After sells service | In time, High efficiency, Satisfiable |
|
|
