Brand Name : | CHENG WEN |
Model Number : | P3.91 |
Certification : | CE |
Payment Terms : | T/T, Western Union, MoneyGram |
Supply Ability : | 300 Square Meters |
Delivery Time : | 7-9 days |
Product Model | P3.91 | P4.81 | P6.25 |
Pixel Pitch | 3.91 mm | 4.81 mm | 6.25 mm |
Module Size | 250*250 mm | 250x250 mm | 250x250 mm |
Module Resolution | 64x64 pixels | 52x52 pixels | 40x40 pixels |
LED | SMD2121 | SMD2121 | SMD3528 |
Cabinet Size | 500*1000 mm | 500*500mm 500x1000 mm | 500x1000 mm |
Cabinet Resolution | 128x256 pixels | 104x208 pixels | 80x160 pixels |
Physical Density (dots/m2) | 56636 | 43264 | 25600 |
White Balance Luminance | ≥2000 nits | ≥2000 nits | ≥2000 nits |
Max Power | 5500 W/m2 | 500 W/m2 | 400 W/m2 |
Average Power | 280 W/m2 | 250 W/m2 | 200 W/m2 |
Driving Method | 1/16 scan | 1/13 scan | 1/10 scan |
Gray Scale per Color | 16384 level | ||
Cabinet weight | 15kg/pc | ||
Refresh Frequency | ≥1920 Hz | ||
Input Voltage(AC) | 110 V -240 V | ||
Working Temperature | -20ºC~60ºC | ||
Life span time | ≥100000 hours | ||
Warranty | 6 years |
1. We can provide customers a comprehensive solution delivery of series-related products
2. We can provide customers high quality products which allow they to scream
3. We can provide custom-made service.
4. We can provide customers one year free warranty, and support renewals extended
5. We can provide customers the free installation guidance and technical support
6. We willing to provide any countries and regions in the world with products and technical support. at present, our product has covered more than 100 countries and regions.
Why the lead time of is P5 led video wall longer ?
1.materials purchase: the purchase term of LED lamps is longer,
special imported chips, the lead time takes 4-6 weeks
2.complicated producing technics : need PCB design, cover making,
glue filling, white balance adjust, etc
3.strict structure requirements: design for cabinet, need to
consider windproof, rainproof, lightningproof , etc.
How to help client choose suitable P5 led video wall ?
1.the needs of displaying content
2.visible distance,, visual angle confirm
3. requirements of cabinet resolution
4.requirements of installation environment
5.cost control
What factors should be taken into consideration of screen size
design ?
-There is three important factors in designing screen size:
1.need of displaying content
2.conditions of field and space
3. unit template size (indoor display) or pi, xel size (outdoor
display)
What are the index on the power consume and the requirements for
the power supply OF THE P5 led video wall ?
The power consume of the LED screen have the Average power consume
and the Maximum power consume. We also called the Average power
consume as the Working power consume, it’s the factual power
consume when it’s operating normally. The Maximum power consume is
the power consume when it’s starting or full lighting and the other
extreme situations. The Maximum power consume is the necessary
factor to consider when using the AC electricity power supply, the
depth of the wire and the switch, too. Generally, the Average power
consume is one out of three of the Maximum power consume.
The LED display screen is the big size precision equipment. To
operate in security and stability, the AV 220V power supply input
port of the LED display screen or the connected computers’ power
supply input port need to connect with the ground.
Noted: computers’power supply input port also must be connected
with the body of the computer.
What are the installation requirements of the P5 led video wall ?
Power supply: the power supply connector must be match for the size
of the LED display screen.
220V electricity power supply, live wire, neutral/null wire and the
earth wire.
380V electricity power supply, three live wires, neutral/null wire
and the earth wire.
The intercept area of the live wire is the same as the null.
![]() |
